Performance features:
Dual grinding chamber with a wide body, huge screen area, birotor design, positive and negative rotation at the same time, all these enhance the effective blow of hammer at material.
A special-designed rotor with two different clearances between the hammers and screens meets the need of sieve changing for diverse fitness of grinding;
Side air inlet destroys the circulation layer of material and clean the screen surface effectively, which will significantly increase the grinding efficiency;
The working surface of hammer is welded with hard alloy material, which prolongs its service life;
The imported SKF high-speed bearing ensures its continuous operation with no failure;
Gravity operating door and unique and convenient sieve pressing mechanism;
The safe interlock system of operating door ensures the electrical machine will not be initiated when the door is opened;
It applies to the micro-grinding of piglet feed, feeding yeast, fermented soybean and chemical industries and aquatic feed for shrimps, crabs and fishes.
| Product model | TLWF68*50S | TLWF68*60S | TLWF68*80S | TLWF68*100S |
|---|---|---|---|---|
| Main engine power (KW) | (45-55)*2 | (55-75)*2 | (75-90)*2 | (90-110)*22 |
| Production capacity(t/h) | 4-7 | 5-8 | 8-12 | 10-15 |
